Our company offers undyed and dyed PET films.
Polyethylene terephthalate film (PET)
Polyethylene terephthalate (PET) film in rolls.
Polyethylene terephthalate films are widely used in the manufacture of various types of packaging.
The main advantages of PET film
- Durability,
- High rigidity,
- Shock resistance,
- Good optical properties,
- High barrier properties (resistance to water vapor and gas penetration).
PET is one of the most environmentally friendly materials due to recyclability
The main areas of application of PET-film
- Food packaging (cookies, salads, meat products, dairy products, etc.);
- production of candy wrappers;
- blister packing;
- promotional materials, and many others.
Our company offers clear and coloured PET films (standard colours: white, brown, black)
Possible additives: anti-block, silicone.
Thickness range – PET 150 – 1500 mic.
Spool diameter - 76 mm. / 152 mm.
Winding diameter - up to 1100 mm.
|
Properties |
Unit |
Value |
Test method |
|
Density |
г/см3 |
1,34 |
ISO 1183 |
|
Thickness range |
µm |
150 -1500 |
DIN 53370 |
|
Thickness (deviation from nominal) |
% |
0/+3 |
|
|
Spool diameter |
мм |
76/152 |
|
|
Width |
мм |
90 - 1800 |
ISO 1923:1995 |
|
Width (deviation from nominal) |
мм |
±3 |
|
|
Modulus of elasticity |
Мпа |
1800 - 2500 |
ASTM D 882 |
PET/ PE laminated polyethylene terephthalate film
PET/ PE (PET/PE) is a PET (PET) film laminated with polyethylene. Laminating PET with a PE layer increases resistance to cracking, punctures and alternating loads.
PET/ PE film has excellent heat sealability (due to the PE layer) and frost resistance. Also PET/ PE film has excellent strength and optical properties.
PET films with PE coating are mainly used in the FFS (form/fill/seal) packaging industry, where PE is used as a coating material. Excellent for meat and fish trays, cheese and other products. Possible additives: EASY PEEL easy-open effect.
PEEL allows you to easily separate one surface from another, which had previously been connected by glue, temperature exposure or other means.
This effect is the most common and is used to easily open the package by hand without using any tools packaged meat and dairy products. Peel-effect packaging makes it easier for the consumer to open foodstuffs in order to use the product comfortably.
Peel-effect packaging can withstand sterilization and pasteurization, withstand transportation loads while remaining airtight and are resistant to aggressive environments.
The range of available thicknesses is PET/PE 220 - 1500 μm.
Spool diameter - 76mm. / 152 mm.
Winding diameter - up to 1100 mm.
|
Properties |
Unit |
Value |
Test method |
|
PET / PE thickness range |
µm |
190 -1500 |
DIN 53370 |
|
Thickness (deviation from nominal) PET |
% |
± 6 |
|
|
PE thickness |
µm |
40 |
|
|
Width |
мм |
90 - 1850 |
ISO 1923:1995 |
|
Width (deviation from nominal) |
мм |
±3 |
|
|
Modulus of elasticity |
Мпа |
1800 - 2500 |
ASTM D 882 |
PET/ EVOH/ PE – is polyethylene terephthalate film laminated with polyethylene with additioanl baree layer EVOH (PE/EVOH/PE).
Ethylene vinyl alcohol copolymers (EVOH) are a family of thermoplastic polymers with application in many industrial sectors including packaging, especially, in food packaging. The main characteristic of EVOH copolymers for packaging applications is their outstanding barrier to gases (oxygen, carbon dioxide, etc.) and organic vapors (food aroma).
Material type |
Vapor permeability coefficient (g/m2 in 24 hours at 90% relative humidity and 380C) |
Oxygen transmittance (sm3/m2 in 24 hours at 230С) |
|
LDPE |
15-20 |
3000-13000 |
|
HDPE |
3-12 |
500-3000 |
|
PP cast |
8-10 |
1000-6000 |
|
PP oriented |
5 |
2400 |
|
PVDC |
1-5 |
1-3 |
|
EVOH |
15-50 |
0,2-2,5 |
|
PS |
120 |
2500-7700 |
|
PA |
>150 |
30-100 |
|
PET |
15-30 |
50-150 |
Possible additives: EASY PEEL easy-open effect.
This effect is the most common and is used for easy opening of packaged meat and dairy products by hand without using any tools. Packaging with peel effect makes it easier for the consumer to open food products in order to use the product comfortably.
Thickness range – PET/EVOH/PE 220 – 1500 mic.
Spool diameter - 76mm. / 152 mm.
Winding diameter - up to 1100 mm.
